TECHNICAL DATA
Telescopic height level of drain bowl
(mm): 1550 - 2120
Total volume (l): 95
Diameter drain bowl (mm): 420
Volume of drain bowl (l): 18
2 compressed air connections: male quick release adapter, for Rectus coupling, type 26, NW 7,2 mm
Recommended air pressure (bar): 6
Suction rate probe Ø 5 mm (l/min): 1,0 - 1,5
Suction rate probe Ø 6 mm (l/min): 2,0 - 2,5
Suction rate probe Ø 8 mm (l/min): 3,5 - 4,0
Min. oil temperature (°C): 70
Lacquering of container: window grey, satin, RAL 7040
Lacquering of drain bowl: blue, Pantone 294 C
Media: for waste oils of hazard class A III of known origin with flash points higher than 55°C; or not easily inflammable liquids, not suitable for highly inflammable liquids
Dimensions LxWxH (mm): 600 x 580 x 1520
Weight (kg): 38,5
SPECIFICATION
• A vacuum is generated in the container by means of a venturi system and compressed air
• Manometer / vacuum meter, for pressure and vacuum level indication
• Oil extraction through the dipstick tube
• Level indicator
• Overpressure safety valve, set at 0.5 bar, with a pressure regulating valve
• Male quick release adapter for Rectus coupler, type 26, NW 7,2 mm (20 062), lever ball valve
• Suction hose, 2 m, with spiral spring
• Suction probes, Ø 5 / 6 / 8 mm
• With adapters for BMW, Mercedes, VW, Audi and Smart
• Suction probe holder
• Transparent discharge hose, 2 m, with metal discharge spout and lever ball valve
• Drain bowl with removable strainer and drain grill
• Sturdy handle
• 2 fixed rear wheels, 2 castor front wheels
• Pressure discharge
• Container made from 1,5 mm sheet steel
• With metal protective cover to avoid damage
• Lacquered with oil-resistant hydro-structure paint
• With height adjustable drain bowl
• With visual inspection reservoir, 7 l
SPECIAL NOTES
• The units are subject to the German government regulation for pressurized containers classification group 1 (max. pressure 0,5 bar to drain a waste oil unit)
• If the waste oil drainer is discharged via a pipe system into an oil collection tank, it is recommended to use an overflow protection valve. Please adhere to regional regulations and guidelines of your country
PACKAGING
Dimensions LxWxH (mm): 780 x 580 x 630
Weight (kg): 41,5
Packing unit: 1,0
